Cummins ISX15 X15 Fuel Pump Timing Procedure: ATC 5572562 Professional Guide

Detailed fuel pump timing procedure for Cummins ISX15 / X15 using ATC 5572562 tool.

ATC 5572562 Cummins ISX15 fuel pump timing procedure step-by-step

By Blog Admin • January 21, 2026 • Posted in Diesel Tools, Products

This 12-phase procedure uses the ATC 5572562 tool to time the fuel pump gear train on Cummins ISX15, X15, and QSX15 engines. Ensures accurate alignment during XPI / Next-Gen pump service for optimal performance.

Introduction: Essential Fuel Pump Timing for Cummins Engines

Accurate timing of the fuel pump gear train in ISX15/X15 prevents noise, power loss, and wear. The ATC 5572562 tool, OEM 5572562/5572664 replacement, locks alignment—key for reliable service.

Phase 1-3: Engine Preparation & Access

Secure engine and remove components – Gear housing access
Inspect gear train – Note timing marks
Remove old pump if needed – Clean area
Prepare ATC 5572562 tool – Verify condition
Align pump drive – Initial position

Phase 4-6: Timing & Locking

Insert timing tool – Lock pump gear
Align camshaft marks – Match factory spec
Verify synchronization – No play
Torque pump fasteners – Per sequence
Check alignment again – Confirm lock
Remove tool carefully – No disturbance

Phase 7-9: Reassembly

CRITICAL: ATC 5572562 Timing Setup

Reinstall housing/components – Torque spec
Prime fuel system – No air
Check timing marks – Final verification
Document alignment – Photos/notes
Refill fluids – Check levels
Reassemble covers – New gaskets

Phase 10-12: Testing & Finalization

Start idle test – Monitor noise
Road test load – Verify performance
Final inspection – No leaks/rattle
Schedule follow-up – At 1,000 miles
