Installing a cylinder head or servicing the gear train on a Detroit Diesel 60 Series or 50 Series engine? Follow this step-by-step professional workshop procedure to pin the flywheel at Top Dead Center (TDC), mount the M30138 camshaft timing fixture, index the camshaft drive gear, and torque timing gear bolts with 100% mechanical precision.

Why Improvised Eyeball Timing Methods Cause Catastrophic Engine Destruction

On Detroit Diesel Series 60 and Series 50 engines, overhead camshaft timing directly dictates both valve actuation and electronic unit injector timing. Because the camshaft gear meshes into a gear train subject to backlash adjustments, setting timing requires a dedicated rigid alignment fixture. Technicians who attempt to set camshaft timing using paint marks, chalk lines, or visual alignment frequently miscalculate gear tooth alignment. Being off by even a single tooth shifts the camshaft timing by several degrees relative to the crankshaft. When the engine is cranked over, the pistons travel upward to Top Dead Center while the intake or exhaust valves remain partially extended into the combustion chamber. The resulting collision instantly bends valve stems, cracks valve guides, and breaks piston crowns, dropping valve heads into the cylinders and destroying the entire engine block. Utilizing the 7-pound M30138 Camshaft Timing Tool eliminates these catastrophic service hazards. Anchored directly into the cylinder head face and camshaft gear indexing locating holes, the precision steel fixture holds the camshaft in dead-center phase while the gear train backlash is set and retaining bolts are torqued to OEM specification.

The 5-Step Detroit 60/50 Series Camshaft Timing Protocol

1. Pin Flywheel at Cylinder #1 Top Dead Center (TDC): Rotate the engine crankshaft manually in the direction of rotation until the flywheel timing pin drops into the Cylinder #1 TDC locating hole. *Verify the engine is on the compression stroke.*
2. Clean Camshaft Gear & Cylinder Head Mounting Face: Clean the front face of the cylinder head and the camshaft drive gear thoroughly using solvent. *Verify locating holes and mounting faces are 100% free of dirt, oil sludge, and burrs.*
3. Mount M30138 Timing Tool onto Cylinder Head & Cam Gear: Position the M30138 camshaft timing fixture onto the cylinder head face. Insert the precision alignment pins of the M30138 tool directly into the locating holes of the overhead camshaft drive gear and cylinder head.
4. Set Gear Train Backlash & Torque Mounting Bolts: With the M30138 tool holding the camshaft in dead-center timing phase, adjust the gear train idler gear backlash per Detroit Diesel manual specs. Torque the camshaft gear hub bolts evenly to factory specifications.
5. Remove Tool, Disengage Pin & Verify Engine Rotation: Unbolt and remove the M30138 timing tool. Remove the flywheel timing pin. Bar the engine over by hand two full crankshaft revolutions to verify smooth rotation with zero mechanical interference before installing valve covers.

---
