Extracting seized, road-salted, or corroded universal joint bearing cups from driveshaft yokes on Class 7 and 8 heavy-duty commercial vehicles? Attempting to remove stubborn bearing caps using sledgehammers, socket sockets, or oxy-acetylene torches creates catastrophic driveline hazards. Impact loads from heavy hammers distort precision yoke ears, bend driveshaft tubing, and crush needle bearings, while torch heating destroys heat-treated driveshaft metallurgy, burns out companion flange seals, and introduces extreme rotational vibration. Engineered for commercial truck maintenance facilities, fleet driveline repair bays, and mobile diesel service trucks as a heavy-duty 7-ton mechanical extraction solution, the ATCJ7058 Universal Truck U-Joint Puller provides a complete 13.00-pound high-tensile alloy steel system designed to safely press out bearing cups on Spicer (1610–1880, SPL 140/170), Rockwell (16N–18N, 1710), and Meritor RPL (20/25 Permalube) series universal joints—without damaging expensive yoke assemblies or driveshaft tubes.

The Critical Physics of Driveline Yoke Deformation & 7-Ton Mechanical Advantage

Heavy-duty Class 7 and 8 driveline systems transmit massive engine torque to drive axles through universal joint spiders held by press-fit bearing cups. Operating under chassis in hostile environments, road salt, moisture, and intense thermal loads fuse the outer bearing steel cups directly into the forged iron or steel yoke ears. When technicians attempt to beat out frozen bearing cups using brass drifts or sledgehammers, force is applied off-axis. Off-center impacts spring the yoke ears out of parallel alignment. Even a microscopic 0.005-inch bend in a driveshaft yoke ear alters universal joint operating angles, causing severe driveline vibration, premature pinion seal failure, and catastrophic driveshaft separation at highway speeds. The ATCJ7058 Master Universal Joint Puller completely eliminates these driveline failure points. Featuring a massive heat-treated alloy steel frame rated for 7 tons (14,000 lbs) of mechanical force, the tool legs slip securely behind the driveshaft yoke ear while the central forcing screw centers dead-flat against the bearing cup face. Turning the 1/2" drive forcing screw with an impact wrench applies pure, centered axial pressing force. The tool pushes the bearing cup straight out of the yoke ear bore without cocking or side-loading, keeping yoke ears perfectly parallel and preserving expensive driveshaft assemblies for immediate reinstall.

• Comprehensive Class 7 & 8 Driveline Coverage – Purpose-built to service universal joints on Spicer 1610, 1710, 1760, 1810, 1880, SPL 140, SPL 170; Rockwell 16N, 17N, 18N, 1710 Series; and Meritor RPL 20 & RPL 25 Permalube Series.
• Massive 7-Ton Mechanical Pressing Capacity – Delivers up to 14,000 lbs of continuous mechanical force to shear through severe rust, scale, and corrosion bonds safely.
• Protects Driveshaft Yoke Ears & Tubes – Eliminates sledgehammer impacts and torch heating, preserving exact yoke ear parallelism and rotational balance.
• 1/2" Impact Wrench Compatible Forcing Screw – Heavy-duty heat-treated alloy steel forcing screw designed for rapid 1/2" drive impact operation in busy shop bays.
• Substantial 13.00 lbs Shop-Grade Construction – Built for daily, repetitive use in commercial fleet maintenance programs, heavy truck repair shops, and mobile driveline service trucks.

Stop Hammering Driveshafts. Command Total Heavy-Duty Driveline Service Precision.

The ATCJ7058 Heavy Duty Universal Truck U-Joint Puller- Rockwell, Spicer, Meritor is an essential capital asset for commercial truck repair centers, fleet maintenance facilities, heavy-duty transmission/driveline shops, and mobile service mechanics. Prevent damaged yokes, eliminate dangerous torch cutting, and service Class 7 & 8 drivelines with complete mechanical authority using Apex tools.

Technical Specifications & Driveline Fitment Cross-Reference

Driveline Family / Series	Compatible Universal Joint Models & Specifications
Spicer Series Fitment	Spicer 1610, 1710, 1760, 1810, 1880 & Spicer SPL 140, SPL 170 Series
Rockwell Series Fitment	Rockwell 16N, 17N, 18N, and 1710 Series Universal Joints
Meritor Series Fitment	Meritor RPL 20 and RPL 25 Permalube Series Universal Joints
Max Pressing Force Capacity	7 Tons (14,000 lbs) of continuous mechanical separation force
Part / Model Reference Number	ATCJ7058 (ATC-JT4757 / ATCJ7058 / J7058)
Construction Metallurgy	High-tensile precision-machined heat-treated structural alloy steel
Total Package Shipping Weight	13.00 lbs (Heavy-duty master driveline service tool)

---
