Extracting sheared or seized exhaust manifold studs from cylinder head faces on Caterpillar 3406, 3406B, 3406C, 3406E, C15, or 3408 heavy-duty diesel engines? Attempting to drill out broken studs freehand using handheld power drills, angle grinders, or torch-melting methods causes catastrophic cylinder head casting destruction. Exhaust manifold studs endure severe thermal expansion cycles and exhaust gas corrosion, causing fastener shanks to snap below the deck surface. Freehand drilling inevitably wanders off-center into the soft cast-iron cylinder head threads, ovalizing tapped holes, ruining head sealing decks, or breaching internal coolant jackets. A ruined stud hole requires pulling the cylinder head, expensive machine shop insert repairs, or complete head replacement costing thousands in downtime. Engineered for commercial diesel technicians, CAT dealership rebuild stalls, bus fleet maintenance bays, and heavy equipment mechanics, the M10130 Broken Exhaust Manifold Stud Removal Kit provides a 10.00-pound precision-machined drilling plate and hardened guide bushing system—delivering 100% concentric drill alignment to bore out sheared studs dead-center without nicking OEM cylinder head threads.

The Critical Physics of Guided Drilling Alignment & Thread Preservation

On Caterpillar 3406 and 3408 engines, exhaust manifold studs secure heavy cast-iron exhaust flanges against cylinder head ports to contain high-temperature exhaust gas flow. When extreme thermal cycling causes a stud to snap flush or sub-flush inside the cylinder head, extracting the hard steel stud core requires removing internal thread tension without damaging the surrounding cast iron. Steel drill bits naturally drift away from hardened steel studs toward the softer cast-iron head material. The M10130 kit completely prevents bit wandering through its rigid, application-specific mounting plate. By bolting the alignment template squarely to adjacent intact exhaust stud locations, the hardened drill guide bushings center the drill bit dead-flat over the broken stud shank. Technicians drill a perfectly centered pilot hole through the stud core, relieving outward thread pressure so the stud remnant can be extracted cleanly with a screw extractor or tap—preserving 100% of the original Caterpillar factory threads.

• Targeted Caterpillar Engine Platform Fitment – Purpose-built specifically for exhaust manifold stud extraction on CAT 3406, 3406B, 3406C, 3406E, C15, and 3408 diesel engines.
• Hardened Steel Drill Guide Bushing Template – Bolts directly to the cylinder head face to lock drill bits dead-center over broken stud shanks.
• Eliminates Freehand Drill Wandering & Thread Damage – Prevents drill bits from drifting into soft cast-iron cylinder head castings or breaching water jackets.
• Preserves Original OEM Factory Head Threads – Relieves internal fastener strain to allow clean stud extraction without Helicoil or thread insert repairs.
• Substantial 10.00 lbs Heavy-Duty Shop Build – Precision-machined structural alloy tool steel built for daily, repeatable use in commercial diesel repair shops.

Stop Ruining Cylinder Heads. Command Total Caterpillar Exhaust Repair Precision.

The M10130 Caterpillar 3406 & 3408 Series Broken Exhaust Manifold Stud Removal Kit is an essential capital asset for commercial truck service centers, CAT dealership repair stalls, fleet maintenance depots, and field service technicians. Prevent cylinder head damage, extract broken exhaust studs safely, and service Caterpillar diesel engines with complete mechanical authority using Apex tools.

Technical Specifications

Technical Metric	Value / Fitment Reference Guidelines
Target Engine Platforms	Caterpillar 3406, 3406B, 3406C, 3406E, C15, and 3408 Series Diesel Engines
Primary Operational Function	Concentric guided drilling and clean removal of broken exhaust manifold studs
Alignment Template Architecture	Heavy structural alloy steel plate with hardened drill guide bushings
Part / Model Reference Number	M10130 (M 10130 / 10130)
Construction Metallurgy	Precision-machined high-tensile alloy tool steel with hardened steel bushings
Total Package Shipping Weight	10.00 lbs (Heavy-duty master commercial shop stud removal kit)

---
