Diagnosing diesel fuel in the coolant expansion tank or replacing worn injector cups on a Mack MP8 or Volvo D13 engine? Follow this step-by-step professional workshop procedure to thread and extract carbon-seized sleeve cups safely in-frame using the ATC 88800387 replacement puller mandrel.

Why Worn Puller Collets Cause Severe Cylinder Head Damage

The injector sleeve cup in Mack MP-series and Volvo D13/FM12 engines sits sealed tightly inside the cylinder head water jacket. When carbon buildup and heat glaze lock the cup in place, pulling it requires immense vertical breakout force. A common mistake in heavy repair shops is using worn, rounded, or chipped puller collets. When a worn collet is threaded into a stainless or copper cup, the threads strip under load, sending metal shards down into the engine cylinder and dropping the puller. Even worse, off-angle prying concentrates immense lateral force against the lower cast-iron head bore, galling the sealing landing and creating an un-sealable surface that requires pulling the entire cylinder head for machine shop re-facing. Utilizing a fresh, precision-machined replacement collet like the 2-pound ATC 88800387 ensures 100% full thread depth engagement inside the cup wall, distributing extraction load evenly and drawing the cup straight up cleanly without harming the head.

The 5-Step Injector Sleeve Extraction Protocol

1. Teardown & Port Isolation: Drain the engine cooling system completely and isolate the fuel lines. Remove the valve cover, rocker shaft assembly, and target electronic unit injector. Plug the lower fuel/cylinder drain port with a clean shop plug to prevent debris from falling into the combustion chamber.
2. Inspect & Mount the ATC 88800387 Collet: Inspect the threads of the ATC 88800387 replacement puller mandrel to ensure they are clean and dry. Thread the ATC 88800387 collet onto your master puller drive shaft. Lower the collet assembly down into the target injector sleeve cup.
3. Thread Engaged Collet Jaw: Turn the upper drive screw to tap and thread the ATC 88800387 collet firmly into the inner metal wall of the sleeve cup. *CRITICAL: Ensure full thread engagement before applying vertical pulling force to prevent thread stripping.*
4. Assemble Puller Bridge & Draw Cup: Position the master puller bridge feet flat against the cylinder head deck face around the injector bore. Thread the central forcing nut onto the drive shaft. Using a manual hand socket or breaker bar, turn the forcing nut clockwise smoothly to draw the carbon-baked sleeve cup straight up out of the head bore.
5. Clean & Inspect Head Landing: Once the sleeve clears the head well, lift it away and immediately inspect the cast-iron head bore landing. Clean away all scale, old sealant, and carbon glaze using a brass bore brush and solvent, verifying a clean surface for seating the new replacement sleeve.

---
