Replacing a front gear housing, servicing timing trains, or pulling the camshaft gear on a Cummins ISB, ISC, ISL, QSC 8.3, or QSL9 engine? Prying behind the camshaft gear with jaw pullers, pry bars, or heating the gear face with torches is a direct recipe for chipped gear teeth, bent timing plates, and gouged camshaft journals. The M20164-A Camshaft Gear Remover Kit delivers 100% parallel, linear extraction force to pull pressed camshaft gears cleanly off the nose without removing the camshaft from the engine block.

The Critical Engineering of Cummins Camshaft Nose Pressure & Gear Extraction

On mid-range and heavy-duty Cummins diesel platforms—including the ISB 6.7L, ISC 8.3L, ISL 9L, QSC 8.3, and QSL9 engines—the helical camshaft timing gear is fitted onto the camshaft nose using a tight mechanical interference press fit. This press fit ensures zero slippage under high valve train torsional loads and high-pressure fuel pump drive resistance. When in-frame service requires gear removal, attempting to pull the gear using standard jaw pullers or wedge bars causes catastrophic mechanical failures. Jaw pullers apply point-loading to the outer helical gear teeth, easily chipping tooth edges or warping the gear body. Prying against the thrust plate deforms the camshaft retainer, while applying torch heat destroys the metallurgical temper of the gear and ruins front oil seals. The M20164-A removal system completely eliminates these overhaul hazards. Designed as an exact functional equivalent for Cummins OEM tool 3165093, this heavy-duty kit thread-anchors directly into the threaded hole in the camshaft nose. The pilot adapter and heavy-wall remover body press squarely against the gear hub, applying thousands of pounds of perfectly linear, concentric breakout force down a 100% parallel axis. The helical gear slides off smoothly in minutes without pulling the entire camshaft out of the block, saving hours of labor time.

• Multi-Platform Cummins Compatibility – Custom-machined for Cummins ISB, ISC, ISL, QSC 8.3, and QSL9 engines equipped with a threaded camshaft nose hole.
• Direct OEM Factory Tool Replacement – High-strength direct equivalent for Cummins factory part number **3165093** (316-5093).
• In-Frame Efficiency & Labor Reduction – Pulls pressed camshaft gears directly on-chassis without removing valve covers, pushrods, tappets, or the camshaft assembly.
• 360-Degree Parallel Extraction Force – Thread-anchored pilot adapter prevents tooth chipping, gear body warping, or thrust plate bending.
• Industrial Toolroom Heavy Metallurgy – Weighing a solid 11.00 lbs, this heat-treated alloy steel kit is built for heavy daily use in high-volume diesel overhaul bays.

Stop Prying on Helical Gears. Command Total Cummins Timing Train Precision.

The M20164-A Camshaft Gear Remover Kit is an indispensable capital asset for commercial truck repair centers, fleet maintenance facilities, equipment overhaul bays, and diesel machine shops. Eliminate gear tooth damage, slash repair hours, and pull camshaft gears with complete mechanical authority using Apex.

Technical Specifications

Technical Metric	Value / Fitment Reference Guidelines
Target Engine Platforms	Cummins ISB, ISC, QSC 8.3, ISL, and QSL9 Diesel Engines
Camshaft Interface Mandate	MUST HAVE THREADED HOLE IN CAMSHAFT NOSE
Primary Operational Function	In-frame removal of interference-fit camshaft timing gears without camshaft removal
OEM Special Tool Cross Reference	Direct functional equivalent for Cummins OEM part # 3165093 (316-5093)
Part / Model Reference Number	M20164-A (20164-A / M20164A)
Construction Metallurgy	Precision-machined high-tensile structural shop steel alloy
Total Package Shipping Weight	11.00 lbs (Substantial, heavy-wall shop tool steel module set)

---
