Dealing with a fretted cylinder ledge on a high-mileage Cummins block? Learn the professional technical sequence for mounting the ATC 2200-72A plate to your Porta-Tool housing.

Why Mating Plate Parallelism is Critical

The counterbore ledge on a Cummins N-14 must be machined perfectly parallel to the block deck to ensure the cylinder head gasket fire ring crushes evenly. If your cutter plate has even a microscopic burr or isn't seated squarely into the tool housing, the cutting bit will induce a tapered "wave" onto the cast iron ledge. When you install a repair shim over a wavy cut, the shim will eventually crack or settle under load, leading to immediate coolant-in-oil contamination. Utilizing a precision-machined adapter plate like the ATC 2200-72A ensures that the tool weight is distributed evenly across the deck, forcing the bit to produce a factory-flat landing surface.

The 5-Step Block Deck Prep & Machining Sequence

1. Cylinder Well Triage: Pull the old liner and vacuum all loose carbon and rust from the crankcase. Use a precision dial indicator to sweep the current counterbore depth at 12, 3, 6, and 9 o'clock positions to identify the lowest wear point.
2. Attach the ATC 2200-72A Plate: Clean the mounting flange of your Porta-Tool (PT-2250B or M50133) housing. Bolt the ATC 2200-72A plate squarely to the base of the tool. Torque the mounting screws firmly to eliminate any structural flex during the cutting pass.
3. Index the Tool Assembly: Lower the tool assembly into the cylinder bore. The 5.5" pilot diameter of the plate should center itself perfectly. Secure the tool frame into the engine block deck's head-bolt holes to prevent tool lift.
4. Execute Manual Cutting Passes: Apply a small amount of cutting lubricant to the carbide bit. Turn the drive handle at a steady, rhythmic cadence. Use the feed knob to take very light passes (no more than .001" to .002" at a time) until the entire ledge is cleaned to a bright, flat finish.
5. Final Measurement & Shimming: Remove the tool and wipe the machined ledge clean with solvent. Use a micrometer depth gauge to calculate the exact repair shim thickness (e.g., .010", .020") required to restore the liner's factory protrusion height above the block deck.

---
