Calibrating the fuel injection timing, camshaft synchronization, or overhead valve train on a classic Pressure-Time (PT) fuel system Cummins engine? Attempting to set injector pushrod travel and timing alignment using magnetic base dial indicators, flexible arms, or guesswork leads directly to retarded injection timing, excessive black smoke, sluggish throttle response, and catastrophic valve-to-piston contact. The M20070 Cummins Timing Tool provides a dead-rigid, precision-machined mechanical reference fixture to set PT injector timing across Big Cam, Small Cam, N14, and NH platforms to exact factory specifications.

The Critical Physics of Cummins PT Fuel Injector Camshaft Synchronization

On legendary heavy-duty mechanical Cummins diesel engines—including the 855 Big Cam I-IV, N14, N855, and NH220/250 platforms—the proprietary Pressure-Time (PT) fuel system relies entirely on mechanical pushrod displacement driven by internal camshaft lobes. Unlike modern electronic common-rail systems where ECM software dictates fuel delivery timing, a PT system dictates the exact start and duration of high-pressure fuel injection via the physical relationship between piston travel and injector plunger travel. For complete combustion efficiency, peak cylinder pressure, and clean exhaust emissions, the injector pushrod travel must be synchronized with piston top-dead-center (TDC) down to thousandths of an inch. Attempting to set this precise mechanical timing using universal flexible magnetic dial indicators is extremely hazardous. Magnetic bases flex under heavy shop vibration, and unguided indicator plungers introduce off-axis measurement errors (cosine error). If PT injector timing is set too advanced, violent peak cylinder pressures cause severe engine detonation, cracked piston crowns, and blown head gaskets. Conversely, if timing is retarded, unburned fuel washes cylinder walls, dilutes engine oil, and produces dense black smoke under load. The M20070 timing kit completely solves this metrology challenge. Housed in a custom heavy-duty blow-molded case, this fixture locks directly into the cylinder head deck and pushrod wells—holding dual precision dial indicators on a 100% parallel axis to track piston travel and injector plunger travel simultaneously without flex or error.

• Targeted Cummins PT Fuel System Compatibility – Custom-engineered specifically for all mechanical Pressure-Time (PT) fuel system Cummins engines (N14, Big Cam, Small Cam, NH, NT series).
• Platform Exclusion Note – Engineered exclusively for classic PT platforms; not designed for Cummins B-Series, C-Series, or ISX platforms.
• Dual Dial Indicator Precision Metrology – Simultaneously measures piston travel and injector pushrod displacement to capture exact injection start timing relative to crankshaft position.
• Prevents Valve-to-Piston Interference – Enforces exact OEM camshaft-to-crankshaft synchronization to protect valve train components from mechanical collision.
• Turnkey Blow-Molded Storage Package – Supplied complete with precision dial indicators, extension rods, mounting blocks, and alignment fixtures in a rugged, jobsite-ready case.

Stop Guessing PT Fuel Timing. Command Total Mechanical Cummins Accuracy.

The M20070 Cummins PT Type Engine Timing Tool is an essential capital asset for commercial truck repair shops, heavy equipment overhaul bays, diesel machine shops, and classic Cummins restoration specialists. Protect N14 and 855 Big Cam engines, eliminate exhaust smoke, and calibrate PT fuel timing with complete mechanical authority using Apex.

Technical Specifications

Technical Metric	Value / Fitment Reference Guidelines
Target Engine Platforms	Cummins Mechanical PT Type Engines (N14, 855 Big Cam I-IV, Small Cam, NH220/250, NT)
Excluded Engine Platforms	Will NOT work on Cummins B, C, or ISX Series Engines
Primary Operational Function	Precision measurement of piston TDC and PT injector pushrod travel for fuel timing calibration
Part / Model Reference Number	M20070 (20070)
Included Metrology Hardware	Dual precision dial indicators, extension rods, mounting blocks, alignment bases
Case & Shipping Specification	Heavy-duty blow-molded carrying case (Shipping Weight: 7.00 lbs)

---
