Step-by-Step: How to Use the ATC10225A Shim Cutter Plate for Perfect CAT 3406/C-15 Counterbore Shims
Step-by-Step: How to Use the ATC10225A Shim Cutter Plate for Perfect CAT 3406/C-15 Counterbore Shims
Oval or thin shims = blown head gaskets. The ATC10225A 5.4" shim cutter plate guarantees perfect cuts on CAT 3406, 3408, and C-15 blocks. This guide shows you how to use it with M50133 or M50139 for leak-free rebuilds.
Shipping Weight: 7.00 lbs • Eligible for Free Shipping
Step 1: Install Plate on Counterbore Tool
Secure ATC10225A to M50133 or M50139. Align 5.4" bore with block.
Step 2: Set Depth & Install Bit
Use PT-2200-93 bit. Set depth per CAT spec (e.g., 0.030" shim).
Step 3: Cut the Shim
Rotate tool slowly. Let the 5.4" plate guide a clean, round cut. Vacuum chips.
Step 4: Verify & Install
Mic shim thickness. Install in block. Torque head per CAT sequence.
