Why the ATC 4919360 Bracket is Mandatory for Cummins ISX15 and X15 Head Service
Eliminate off-axis engine hoist sway and lift large-bore diesel castings with absolute balance.
Wrestling a massive, fully loaded dual-overhead-cam cylinder head out of a Freightliner or Kenworth engine bay is a recipe for back injuries and ruined engine decks. The ATC 4919360 lifting bracket provides the balanced, zero-tilt control required for a safe, damage-free extraction.
The Crucial Physics of Large-Bore Head Hoisting
On modern heavy-duty platforms like the Cummins ISX12, ISX15, and X15 series, the cylinder head is a monumental piece of solid cast iron. Attempting to hoist this immense weight using generic chains, unguided straps, or mismatched eye-bolts is an absolute trap. If the head tilts by even a few degrees during vertical travel, its razor-sharp bottom mating face will swing and gouge the precision-ground block deck or snap the sensitive alignment dowel pins cleanly in half. Any slight surface scratch across the combustion deck will compromise head gasket fire-ring crush, guaranteeing an immediate post-rebuild compression blowout. The ATC 4919360 lifting bracket eliminates this vulnerability completely by securing directly into the factory head bolt pattern, creating a fixed center of gravity and a pivoting lifting eye that keeps the head perfectly flat and level.
- Massive 750 lb Rated Safe Lifting Limit – Engineered to effortlessly handle fully loaded cylinder head castings including valves, springs, and heavy dual camshafts.
- Direct OEM Specification Match – Designed as a high-strength direct functional replacement for Cummins factory tool number **4919360**.
- Symmetrical Bolt-Down Indexing – Mounts seamlessly using the engine's structural cylinder head bolt locations to eliminate load shifting or sliding.
- Pivoting Overhead Hoist Eye – Enables smooth maneuvering and tilt adjustments through tight firewalls and narrow sleeper-cab hood geometries.
- Heavy-Duty Shop Mass – A substantial 28.00 lbs structural tool steel casting engineered to handle daily checkout abuse in high-volume fleet environments.
Protect the Deck. Secure Your Technicians.
The ATC 4919360 Cylinder Head Lifting Bracket is a foundational piece of infrastructure for professional commercial transport yards, independent diesel machine shops, and engine remanufacturing networks. Stop wrestling with unguided weight—lift level, lift safe, and protect your shop margins.
Zero-Tilt Extraction. Complete Block Deck Protection.
Order the 4919360 Bracket – $450.00Technical Specifications
| Technical Metric | Value / Application Guidelines |
|---|---|
| Engine Compatibility Range | Cummins ISX12, ISX15, ISX, and X15 Heavy-Duty Diesel Engines |
| Lifting Capacity Profile | 750 lbs Maximum Rated Structural Working Load Limit |
| OEM Equivalent Cross | Direct blueprint substitute for Cummins OEM Part # 4919360 |
| Mounting System | Symmetrical flange plate anchoring into factory head bolt configurations |
| Material Forging | High-strength, industrial-grade structural tool steel armor plate |
| Product Shipping Weight | 28.00 lbs (Heavy shop-ready lifting fixture) |
